CBL-U600-020

USB4 Gen2x2 20Gbps Cable

Full features: video, data transfers and power delivery in only one USB-C cable
PD3.1 EPR certified, USB Power Delivery up to 240W(48V/5A)
Supports Thunderbolt 3
DisplayPort Alternate Mode (Alt Mode)
Supports 8K@60Hz video transmission
Backward compatible with USB3.2 & USB 2.0
Supports USB4 Gen2x2 20Gbps bandwidth
Reversible cable direction and plug orientation

This 2-meter high quality USB4® Type-C Gen2x2 cable has been certified by USB-IF. Designed with a robust twisted pair structure to deliver high reliability and 20Gbps signal transmission without loss. The power delivery (PD3.1 EPR certified) supply power charging of 240W (48V/5A) for connected devices.

Signal Support
USB Standards	USB4
Alternate Mode	Yes
DisplayPort Standards	2.1
Video Format	8K@60Hz, 4K@120Hz, 1080p@60Hz
Data Rate	20Gbps
Power Delivery	240W(48V/5A)
Connector	USB Type-C to Type-C Connector

Physical Properties
Op. Temp.	-20°C to 80°C
Humidity	0% to 85% RH
Bending Radius	20mm
Pulling Force	5kg

ORDERING INFORMATION

Model No.	Product Description
CBL-U600-020	USB4® Type C Gen2x2 20Gbps cable, 20M
