CSI-8H8CV2IR

The 8 HDMI™ over CAT6 Point-to-Point Transmitter (with IR Matrix) offers advanced point-to-point distribution of HDBaseT™ signals up to lengths of 100m over single CAT5e/6/7 cable. It supports digital audio formats such as LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Mater Audio. 3D content can be displayed when connecting a 3DTV and 3D source. With the potential for use with any standard 8 HDMI output matrix or distribution amplifier, this solution can work with any matrix / DA to add 8 HDBaseT outputs with only a single power supply. This device has the added functionality of an in-built 8×8 IR matrix system which allows for two-way control of the sources and screens. This transmitter solution can provide Power over Ethernet (PoE) to the receiver unit adding additional integration benefits.

Video Bandwidth	300 MHz/10.2 Gbps
Input Ports	8×HDMI, 9×IR Extender, 1×RS-232
Output Ports	8×CAT5e/6/7, 9×IR Blaster, 1×RS-232
Input/Output Resolution	VGA~WUXGA, 480i~1080p@24/50/60, 4kx2k@24/25/30
ESD Protection	Human-body Model: ±8 kV (Air-gap discharge) ±4 kV (Contact discharge)
Power Supply	24 V/6.25 A DC (US/EU standards, CE/FCC/ UL certified)
Dimensions	432 mm (W)×210 mm (D)×93 mm (H)
Weight	3312 g
Chassis Material	Metal
Silkscreen Color	Black
Operating Temperature	0 ºC~40 ºC/32 ºF~104 ºF
Storage Temerature	−20 ºC~60 ºC/−4 ºF~140 ºF
Relative Humidity	20~90 % RH (non-condensing)
Power Consumption	90 W (Including Transmitter)
