DigiLink Optical Multiplexers

Optical Multiplexers

Description

Artel’s DigiLink media transport platform offers a comprehensive set of optical multiplexing solutions for DWDM, CWDM, and WDM. These multiplexers, in conjunction with other DigiLink solutions or third party equipment, allow the creation of flexible, space and fiber efficient, optical networks.

Artel designed its optical multiplexing products to address the issue of space and fiber constraints. For space efficiency, each module takes only one bay in a DigiLink chassis. By using ITU standard filters and optics, multi-vendor, cost-effective, and fiber efficient video and Ethernet can be created. Completely passive and designed with the latest optical filters, Artel’s DWDM, CWDM, and WDM solutions are extremely reliable, cost-effective, and feature low insertion losses.

Features

Optical multiplexer features

• Low optical losses
• Passive design for reliability
• Bi-directional
• Industry standard ITU wavelengths
• Industry standard LC/PC connectors
• Most modules include expansion port (passes all other wavelengths)
• Compatible with all DigiLink chassis (including DL4000P passive 4 slot chassis)

WDM features (Model Numbers: DLOW1, DLOW2, DLOWE)

• 1310nm and 1550nm combiner/splitters
• Single or dual WDM options
• External WDM conserves chassis slot
• Split ratios from 50/50 to 1/99

CWDM features (Model Numbers: DLOCxx)

• Industry standard ITU G.694.2 wavelengths
• Optically multiplex up to 18 channels over a single fiber
• 4, 8, 10, and 18 channel options
• Multiple 4 channel options

DWDM features (Model Numbers: DLODxxx)

• Industry standard ITU G.694.1 wavelengths
• Optically multiplex up to 40 channels on a single fiber
• 4,10, 20, and 40 channel options
• Interconnect modules to enable 40 channels in a single 1RU chassis

Dual Window Wide Band Optical Splitters (Model Numbers: DLOS2-xx)

Optical Production Switch (Model Number: DLOSW1)

• Supports bi-directional applications
• Manual over-ride
• Supports all wavelengths
• • WDM (1310 – 1550)
  • CWDM ITU G.694.1
  • DWDM
