KFM-1720U 8K HDR

17” 8K 1RU drawer monitor

KFM-1720U, is a 17” 8K 1RU drawer monitor with 4x12G SDI inputs/outputs, supports upto 8192×4360 60P signal with quad 12G SDI inputs. 3D LUT color calibration with Klein K10 probe provides an excellent picture quality. It is a good choice for 8K, 4K OB Van, EFP, studio applications.

Highlights

– 3840×2160 4K resolution

– Support 8K SDI signal 8192×4320 resolution

– 12 Bit Video Processing, image no delay

– 4 x 12G-SDI inputs and outputs (6G/3G/HD/SD-SDI auto detect)

– 4K 12G-SDI single link signal, up to 4096 x 2160 60p

– 4K 12G-SDI quad link signal, up to 8192×4320 60p

– 4K/8K signal: 2 Sample Interleave (2SI), Square Division (SQD)

– 1 x SDI SFP+ module optical input cage

– 4K Mode, Quad-Split Mode, FHD single picture mode

– 4 x SDI Quad-View: mixed inputs & frequency rates

– Free Quad-View (boarder control/window adjustment)

– Payload ID display

– Color Space & EOTF Curves Auto Setting, matching(REC709/REC2020)

– Color Space (REC709/EBU/DCI-P3 D65/DCI-P3/REC2020/Bypass)

– HDR: PQ (ST2084), HLG (1.0, 1.1, 1.2, 1.3, 1.4, 1.5)

– Sony Camera Log Curves: Slog, Slog2, Slog3

– Canon Camera Log Curves: Clog, Clog2, Clog3

– ARRI Camera Log Curves: LogC

– Panasonic Camera Log Curves: Vlog, Vlog (softroll)

– Gamma (2.0, 2.2, 2.4, 2.6)

– 4K HDR Waveform, Vector Scope, Marker/Box Control Function

– 3D LUT Color calibration with ColourSpace & CalMAN

– 3rd-party 3D LUT files import(USER1/USER2)

– S1-S8 Eight Selectable Scene Settings

– Picture Flip, Focus Assist, False Color, Zebra

– SDR and HDR comparison, Darkness Check

– Full Scan, Over Scan, Blue/Mono Only

– 16ch Embedded Audio Level Meters

– Dynamic and Static UMD/IMD Display (TSL3.1/4.0)

– 608/708 CC Closed Caption

– Key Lock, Video Freeze

– Firmware upgrade/LUT file import via USB/Ethernet

– GPI (selectable/markable windows)

– Aluminum Alloy Casing, Built-in Speaker

Product Descriptions

8K Signal, Native 4K Resolution

Supporting 8192×4320 8K signal, including 4320p 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60p. With advance image processing, 8K HDR monitor restores a real world for eyes.

17"8K HDR Monitor

Motion-Adaptive Interlace to Progressive

Realizing quick response of the fast moving image, avoids duzzy, saw tooth and other problems, ensures clearer and smoother image, well-satisfied high-end demanding workflows such as live sports, camera shaking and rolling subtitles etc.

17"8K HDR Monitor

3D LUT Color Calibration

Compatible with ColourSpace and Calman calibration software, Konvision monitors apply K10-A probe(professional level) to achieve a precise color. Monitor's also workable with universal colorimeters including CA210, CA310, CS200, CR100, CR250, X-Rite i1 Display.

32" 8K HDR monitor

2SI and SQD 4K/8K signal

27”8K HDR Monitor

4K/8K 2 Sample Interleave (2SI) :Pixel based segmentation

27”8K HDR Monitor

4K/8K Square Division (SQD) :Quadrant based segmentation

Free Quad View

User can input 4 x 12G-SDI signals or 4x12G/6G/3G-SDI signals  to quad-view, support different SDI formats with mixed inputs and different frequency rate, supporting boarder control and window adjustment.

17”8K 1RU drawer monitor

EOTF Curve Conversions

Konvision KUM 4K,8K and KVM-6X series supports a variety of EOTF curve conversion applicable to the broadcast industry and digital film standard. A preset of lots of HDR log, SDR logs and gamma curve selection, so as to realize the perfect combination with the camera system.

31” 4K HDR P3 OLED Master Monitor

4K BOX Control

The BOX Control function can flexibly set the height and width of the marker frame on the monitor, and can be adjusted up, down, left and right. Users can flexibly adjust according to the frame ratio, which brings great convenience to program production.

31” 4K HDR P3 OLED Master Monitor

Darkness Check

Increasing the brightness and contrast ratio in the dark areas, Darkness Check can show more shadow details of the input signal. Darkness Check can be used for double checking the shadow detail of the dark areas to avoid any missing infomation.

32" 8K HDR monitor

High Dynamic Range(HDR)

Konvision KUM 4K, 8K and KVM-6X series support HDR display. Adjustable HDR modes include PQ(ST2084), HLG with Rec 2020 color gamut. It reproduces a greater dynamic range of luminosity and provides extremely high level picture quality.

17"8K HDR Monitor

4K HDR Waveform (Alarm), Vectors

4K HDR Waveform. SDI supports Waveform, Vectorscope, Histogram. When luminance reaches or exceeds the preset value, the over exposure areas will be red marked (Waveform Alarm).

27”8K HDR Monitor

False Color

Check exposure of the image.Blue, cyan, green, yellow, orange and red color be displayed in turn to show the luminance or brightness values of the image from darkest to brightest, enables an achievement of proper exposure without applying external test equipment.

17"8K HDR Monitor

Focus Assist

Focus assist aids the camera operator in obtaining the sharpest possible picture, it will mark with red color where the sharp edges appear on the screen.

17"8K HDR Monitor

Zebra

Display the overexposed areas(too bright) of the image with zebra stripes, aids the camera operator to control the luminance, in order to avoid overexposure. This feature is very effective for proper exposure.

17"8K HDR Monitor

Specifications

Panel
LCD Screen LCD
Display Size 17.3"
Resolution 3480×2160
Aspect Ratio 16:9
Viewing Angle 178°(H) / 178°(V)
Color Depth 16.7M
Brightness 400cd/m²
Contrast Ratio 1000:1
