CDPS-U42HPIP

UHD+ 4×2 HDMI Multiviewer

4 HDMI inputs and 2 mirrored HDMI outputs
Seamless switching (no loss of sync to display) when switching sources in both full screen and multi-window modes
Supports PiP (Picture-in-Picture), side by side, 3+1 quad view, and 2×2 quad view display options with independent audio source selection Note: 4K@50/60Hz output supports 2×2 Quad View only and is limited to 1080p/4K sources.
Supports the ability to store a multi-window arrangement as a preset that can be recalled later
Each window can have a border with a selectable color
Uploadable and freely positioned graphic logo support Note: The logo and border features are not available when the output is set to 4K@50/60Hz.
Supports easy adjustment of window size, position and settings in the PiP windowing mode via the WebGUI
Matrix mode supports input and output resolutions up to 1080p@60Hz with a single shared audio source (Outputs are mirrored at higher resolutions)
Controllable via front panel buttons, WebGUI, Telnet, RS-232, and IR remote

This 4 by 2 Multiviewer is a high performance HDMI switch with integrated scaling and multi-windowing technology. It is an ideal solution for monitoring or displaying multiple sources simultaneously for use in control rooms, conference rooms or classrooms. Video resolutions up to 4K@60Hz and LPCM audio up to 7.1 channels at 192kHz are supported on both input and output and this unit is fully compatible with the HDCP 1.x and 2.2 standards.

Any of 4 different HDMI sources may be displayed individually, full screen, or they can be displayed using a variety of multi-window modes including quad view and PiP with the output being sent to 2 mirrored HDMI outputs (4K@50/60Hz output supports quad view and full screen only). Management of input/window routing, position and sizing can be controlled easily by use of the front panel controls as well as by WebGUI, RS-232, Telnet, and IR remote control options.

Interfaces
Input Port	4 HDMI
Output Port	2 HDMI 1 Analog Balanced (Terminal Block)
Control I/O	1 LAN (RJ-45) 1 RS-232 (Terminal Block) 1 USB (Type A)

Video
HDMI Compliance	HDMI 2.0 (DVI 1.0)
HDCP Compliance	2.x
Input Signal Type	4096x2160p@60 8bit RGB
Output Signal Types	3840x2160p@60 8bit RGB

Resolutions
Maximum Input	HDMI	4096x2160p@60 RGB
Maximum Output	HDMI	3840x2160p@60 RGB

Audio
HDMI	LPCM (8 Channels), Bitstream, High Bit Rate Bitstream
Balanced Out	4 Vrms S/N Ratio: > 80dB (1kHz with 0dBFS)

Enclosure
Chassis Material	Metal (Aluminum)
Chassis Color	Black
Dimensions (W×H×D)	438mm×44mm×268mm [Case Only] 438mm×49mm×276mm [All Inclusive]
Weight	3,400g

Power
Power Supply	12V/3A
Power Consumption	27.5W

Field Firmware Update
Interface	PC Update, WebGUI

Ordering Information
Model No.	Product Description
CDPS-14TW	HDMI 1×4 TV Wall
